SP COTE-100 (Thixotropic Water Based Ziron Coating)
SP COTE-100 is a high Zircon base coating from the SP Cote range of foundry coatings. It is awater based coating with remarkable stability of fuspension, good covering ability with firm bonding on substrate.
SP COTE-100 has the following advantages as a versatile foundry coating mainly in non-ferrous metal industries for launders, CI moulds & in steel, Alloys Steel, Cast Iron foundries for cores, moulds.
SP COTE-100 has refractories, good binding properties.
- Mix the product SP COTE-100 thoroughly and the use the material for brushing, dipping and spraying applications as per required dilution on CI Mould in Aluminium Alloy plants, on No bake/cold box/shell core/oil cores in casting plant
- For brushing use product as it is or requisite dilution with water.
- For dipping dilute the product by 90:10(product:water) ratio with water.
After applying coating,air dry the core/mould for 10 to 20 minutes and then dry in oven at 150'C to 160'C for 20 minutes or by torching.
The physical properties of SP COTE-100 are as follows:
- Color : Off White
- Apperance : Thick Liquid
- Specific Gravity : 1.60 to 1.80@(27+-3)'C
- Viscocity by B6 Cup : 14 to 20 secs.@(27+-3)'C
- Coating by brushing(as it is) : No peel off/No cracks
- By Dipping on dilution 90:10 : No peel off/No cracks
- (P:W)
40 kg P.C.
6 months
Above information is true & accurate based on controlled laboratory testing, however user is resonsible for determining suitability for application at their end,no guarentee is implied since the conditions in actual use differ widely & beyond our control.
